Unlock the full potential of your products with LMB Innovation's revolutionary Electro Magnetic Coupling (EMC) technology. Our patented solution is designed to supercharge your existing offerings, delivering unparalleled performance and efficiency. Whether you're a leading manufacturer of land, sea or air products, or a trusted provider of cutting-edge solutions, integrating an EMC into your product will catapult you ahead of the competition and into a new era of success.
An Electromagnetic Coupling (EMC) is a revolutionary new device that replaces all conventional transmissions, gearboxes, CVTs, etc. The EMC also makes clutches, torque converters and other such mechanical components redundant.
With only two moving parts, the EMC allows a power source (i.e. an engine) to operate at its optimal RPM and maintain that RPM while enabling the connected load (wheel/s, propeller etc) to vary its RPM from standstill through to its peak rated RPM.
Electricity is produced as a by-product of the operation of the EMC. This in turn can be utilized to power other systems or accessories.
The EMC technology employs a conventional electric motor/generator, comprising a rotor linked to a power source (engine) and a stator that can rotate freely. This rotatable stator, referred to as a rostator, is coupled to an output such as a wheel or a propeller. When the engine operates at its selected RPM, the rotor turns relative to the rostator and they become magnetically coupled. This coupling generates an electrical current in the windings, which is then transmitted to a controller via sliprings and brushes. By adjusting the electrical load through the controller, the RPM of the rostator (connected to the output) can be varied. Consequently, the rostator can rotate independently of the rotor, effectively driving the wheel, propeller, or other connected output at a variable RPM while the rotor RPM remains constant.
True hybrid performance. Lower complexity and better efficiency. Smoother power delivery.
With the addition of a front hub motor, 2WD now possible with added performance and grip.
High torque capability. Continuous power delivery to traction tires. Engine can operate continuously at max torque for maximum efficiency. Hybrid trucks now a possibility.
The electrical energy generated from the EMC can power on-board systems or accessories
Max performance with continuous delivery of power with the engine maintained at peak RPM.
V2L capability in disaster zones to power necessary life supporting devices.
Steam generation from electrical production of EMC aiding in powering alternate fuel vehicles.
Hydrogen generation from electrical production of EMC extending range or allowing for a reduction of fuel carried through on the go top-up.
Allows V2L for essential and life sustaining devices in remote communities.
Imagine a future where your vehicles/products operate more efficiently, reliably and sustainably. Our Electromagnetic Coupling (EMC) technology makes this a reality. By licensing our patented innovation, you'll gain a competitive edge in the market, reduce production costs and improve your products performance.
Join the revolution in transportation technology and partner with us to unlock the potential of your vehicles/products. Let's work together to shape the future of mobility.
LMB Innovation is located in Queensland, Australia
Provisional Patent N# 2025900963
